Brand:
TOB NEW ENERGYitem no.:
TOB-YXY-TQ55order(moq):
1Payment:
L/C,T/T,Western Unionproduct origin:
Chinashipping port:
XIAMENLead Time:
7
SPECIFICATIONS
Overview of functions:
Suitable for the nuances of film thickness accurate assessment study,such as battery materials thin-film battery materials, crystal type film.
The technical parameters:
|
Effective coating width |
55 ~ 200mm （customized according to customer requirements） |
|
Dimensions |
110 * 70 * 90mm |
| Coating Thickness |
The thickness adjustable stroke is 5mm. Maximum coating thickness is 1mm (according to your materials) |
|
Accuracy specification |
0.01mm |
|
Grinding |
±2um |
PRODUCT DISPLAY
PACKAGE AND SHIPPING
|
1 Standard exported package : Internal anticollision protection, external export wooden box package 2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode 3 Responsible for the damage during shipping process, change the damage part for free 4 Supply with suitable voltage input and power plug according to customer's country requirements. |
SERVICES
|
1 We supply machines with battery technology support. 2 We can also supply a full set of materials for lithium battery including polymer battery, cylinder battery, mobile phone battery, EV battery. 3 We can also supply a full set of lithium battery equipment for lab research, pilot scale research and production line. 4 We can also supply a full set of battery technology for battery design, research and producing. |
