Single Column Pneumatic Punch Machine

Compressed air as power source, simple operation

Brand:
TOB NEW ENERGY
item no.:
TOB-YBQD-63
order(moq):
1
Payment:
L/C,T/T,Western Union
product origin:
China
shipping port:
XIAMEN

inquiry now

Product Detail

Single Column Pneumatic Punch Press Machine

SPECIFICATIONS

1.Compressed air as power source, simple operation
2.No oil pressure system produced by the noise, environmental pollution, energy saving and consumption reduction
3.Multiple functions: press bearing, punch hole, riveting, assembling, etc
4.The opening height can be adjusted flexibly according to the size of the product or mold
5.The output size is controllable, only need to adjust the intake pressure, simple, convenient
6.Safety design, ergonomic, suitable for long-term operation
7.Press retention time can be adjusted with counter
8.Optional quick exhaust valve to speed up descent speed and improve efficiency
9.Optional with high, medium and standard working table

Model	TOB-YBQD-63
Maximum Working Height	290mm
Minimum Working Height	90mm
Workbench Area	125*125mm
Cylinder Specification	Diameter63*100 mm
Total Cylinder Stroke	100mm
Cylinder Adjustable Stroke	50mm
Power Supply	AC220V,50-60Hz
Air Pressure	0.3-0.8Mpa

PRODUCT DISPLAY

pneumatic punching machine pneumatic punch press machie
