Force Range

1~20KN

Tester Architecture

Free Stand & Vertical extrusion

Power Input

220V 50 Hz

Force Deviation

≤±1% Full-scale Range

Unit Shift

Kgf,lbf,n,kn,kpa,mpa

Crushing Velocity

1~ 900mm/min(controllable)

Crushing Velocity Accuracy

≤±0.5% Full-scale Range

Crushing Travel

300mm

Crushing Motion Accuracy

≤±1% Full-scale Range

Available Battery Size

W400 X D400 X H300mm

Voltage-Reducing Controlling Method

The pressing plate returns or returns after crushing force continues for a fixed time if voltage drops into a fixed value.

Crushing Force Controlling Method

The pressing plate returns or return after crushing force continues within pre-set time if pressing force reach set value.

Displacement Control

After paused in a period if the pressing tray down to predesigned position , pressing tray will continue second displacement and pause, by repeating such a working mode till to final displacement and pressing tray return after a period maintaining.

6.12Emergency Button

This crushing tester designed with Emergency stop function

6.13 Voltage Resolution

1mv

6.14 Test Terms

Force, Displacement (Deformation), Voltage, one from three

projects or all three projects

6.15 Crushing Time Maintaining

0~99 Hours 99 Minutes & 99 seconds, time can be controllable to

control the deformation and stop if test fulfilled.

6.16 Industrial Communication

Computer Control，ensure stability and real-time of remote sampling, with explosion-proof function, all data can be store and print through computer with Excel format.

6.7Driving Method

Servo Motor Driving

6.8 Nail Penetration Speed

1 ~40mm/s(Controllable)

6.9Tungsten steel needle

Φ3X100MM 6 pieces  Φ4X100MM 6 pieces

Φ6X100MM 6 pieces
