TOB Inert Atmosphere Vacuum Glovebox

Glovebox is a sealed container that is designed to allow one to manipulate objects where a separate atmosphere is desired. Built into the sides of the glovebox are gloves arranged in such a way that the user can place their hands into the gloves and perform tasks inside the box without breaking containment. Part or all of the box is usually transparent to allow the user to see what is being manipulated.

Brand:
TOB NEW ENERGY
item no.:
TOB-GB
order(moq):
1
Payment:
L/C,T/T
product origin:
China

inquiry now

Product Detail

Inert Atmosphere Vacuum Glovebox

Specifications

The glove box is a laboratory equipment that fills the box with high purity inert gas and circulates and filters out the water, itch, organic gas and other substances in it. Also called vacuum glove box, inert gas protection box. The main function is to remove O2, H2O, organic gases; it is widely used in ultra-pure environment without water, oxygen and dust.

The Function and Principle

The working gas in the glove box is circulated between the box and the purification column (water-oxygen adsorber ) under the control and monitoring of PLC through pipes and circulating fans.When the working gas circulates through the purification column, the water and oxygen contained in it are adsorbed off and then returned to the box. With the circulation time, the water and oxygen content in the working gas inside the box is gradually reduced and finally reaches the index of less than 1ppm.The purification column will be saturated with adsorption after a certain time cycle, and can be regenerated and reused.

When the temperature decreases T1,the molecular sieve water saturation C1 increases and can absorb a large amount of water.

When the temperature rises T2, the molecular sieve water saturation amount C1 decreases, and the adsorbed water will be released and evaporated.

Composition

Size and parameters

Model		TOB-1220-1 Single-station/ TOB-GB-W Large warehouse	TOB-GB-D Multi-station	TOB-GB-JX Double purification
Size of Operating surface （mm） L / W / H	Single station (single-sided)	1220×750×900		1220×750×900
	Doublestation (single-sided)		2440×750×900 1800×750×900	2440×750×900 1800×750×900
	Doublestation（Opposite）		1220×1000×900	1220×1000×900
	Three gloves (single-sided)		1500×750×900 1800×750×900	1500×750×900 1800×750×900
	Three-station (single-sided)		3660×750×900	3660×750×900
	Four-station (single-sided)		4880×750×900	4880×750×900
	Four-station (opposite)		2440×1000×900	2440×1000×900
	Six-station (opposite)		3660×1000×900 3660×1200×900	3660×1000×900 3660×1200×900
	8th-station (opposite)		4880×1000×900 4880×1200×900	4880×1000×900 4880×1200×900
	12 stations (opposite)		7320×1000×900	7320×1000×900
Control system		Siemens S7	Siemens S7	Siemens S7
Touch screen		Siemens S7′′	Siemens S7′′	Siemens S7′′
Purification column		Single column	Single column	Doublecolumn
Fans		90 m³ / h	90 / 145 / 180 m³ / h	90 / 145 / 180 m³ / h
Vacuum pump		8 m³ / h	8 / 12 / 16 m³ / h	8 / 12 / 16 m³ / h
Water index		＜1PPM	＜1PPM	＜1PPM
Oxygen index		＜1PPM	＜1PPM	＜1PPM
Applications		R&D type Suitable for university research	Universal type Suitable for research and small-scale production	Production-type Suitable for efficient mass production

More glove boxes from TOB NEW ENERGY

Model	Name
TOB-GB-FC	Viewable Window Square Cabin Glove Box
TOB-GB-FL	O-ring Vacuum Seal Flange Window Glove Box
TOB-GB-ZK	Glove Box Vacuum Coating All-in-one Machine
TOB-GB-W	Automatic Large Warehouse Door Glove Box with IOT Series
TOB-GB	Glove Box with Oven for Lithium Ion Battery and Supercapacitor Please Contact Us

Glove box in different lengths

The depth and height diagram

Glove box combination

Email : tob.amy@tobmachine.com

Skype :amywangbest86

Whatsapp/Phone number :+86 181 2071 5609
