Irregular Hard Carbon Powder Materials for Sodium ion and Lithium ion Battery

Provides TOB-Na-HC01 high pure Irregular hard carbon for Sodium ion(Na-ion) and Lithium ion(Li-ion) battery anode materials.
  • Brand:

    TOB NEW ENERGY
  • item no.:

    TOB-Na-HC01
  • order(moq):

    50g
  • Payment:

    L/C,T/T
  • product origin:

    China
  • shipping port:

    XIAMEN
Product Detail

Irregular Hard Carbon for Sodium ion(Na-ion) and Lithium Battery Anode Materials


Specifications


Hard carbon material is considered to be the most likely anode material for sodium ion battery due to its advantages of abundant resources, low cost, non-toxic environmental protection and low sodium storage potential.

The larger layer spacing of hard carbon can promote the embedding of sodium ions into the material. The microporous structure formed by graphite-like microcrystals can provide more sites for sodium storage, so hard carbon is a promising material for sodium storage.


We can also provide the Spherical Hard Carbon Powder.


Model: T-Na-HC01

MOQ: 50g/bag

Product Name: Irregular Hard Carbon Powder

Molecular Formula: C

The Molecular Weight: 12

Reversible Capacity: 250mAh/g

Character: Black powder

Purpose: Battery anode material for lithium ion secondary battery and Na-ion battery

Features: High purity 99.9%+, very suitable for scientific research and production.


Item

Unit

Analysis Result

Method

Particle Size

D10

μm

4.9

Laser diffraction method: The particle size analyzer of the British Malvin2000

D50

μm

7.9

D90

μm

12.7

Dmax

μm

21.1

Tap Density

g/cm3

1.01

FZS4-4B type automatic tap density meter. Beijing iron and Steel Research Institute.

Reversible Capacity

mAh/g

250

Land test device from Wuhan
