Compact Vacuum Sealer For Vacuum Pre-sealing and Final Sealing

Model

 Compact Vacuum Sealer   TOB-D-YF400

  Source voltage

AC220v 50hz

  Heating pipe power

1000W,  Φ10MM*400MM

   Warranty

One Year limited warranty with lifetime support

Advantages

1 Sealing Head adopts copper material, good heat transfer effect,

2 With adjust plate, Can apply to different specifications battery, and the adjusting easily

Vacuum degree

-95Kpa - 0

Sealing head TEM

RT-250℃, adjustable

TEM accuracy

±1.5℃

Sealing pressure

0-7Kg/cm2, adjustable

  Sealing time

0-99s can be set

    Sealing blade

Hard type (without rubber, only for Al case sealing,

not suitable for sealing case with tab in between)

Sealing width

5mm, customized

Sealing head length

400mm

 Suitable battery size

(Inner size)

380*300*15mm

  Air source

0.5-0.7MPa (72.5-102psi)

       Dimension(L*W*H)

Sealing Unit : 710*530*720mm

Control Unit: 450*400*230mm

     Weight

Sealing Unit  : 99kg

Control Unit: 19kg
