Laboratory Equipment for Battery Manufacturing

The product line includes: typesetting machine, the positive and negative filling machine, caching machine, the positive and negative combination of machines, plus zinc negative electrode machines, automatic positive electrode into the separator machine, screen shell machines, ink machines.

TOB offers a full set of coin cell assemble line for lithium-ion battery laboratory R&D.

TOB offers the most professional coin cell lab research equipment for our clients.

Full set of coin cell lab line equipment and materials for lithium-ion battery R&D.

Coating width≤280mm  The TOB-SY300J solid state battery electrode coating machine is a three-roll transfer coating machine, can be continuous and intermittent coating, suitable for a variety of substrate surface coating process

Nickel strip for battery packing welding tab width 3mm

1600 chamber furnaces SPECIFICATIONS Model TOB-DSP-KF1600-I TOB-DSP-KF1600-II TOB-DSP-KF1600-III TOB-DSP-KF1600-IV TOB-DSP-KF1600-VI TOB-DSP-KF1600-VI TOB-DSP-KF1600-VII Power 3 KW 5KW 7KW 9KW 12KW 21KW 65KW Furnace tube size(mm) 160X150X150 200X200X200 300X200X200 300X250X250 400X300X300 500X400X400 1200X600X600 Dimension 510X490X780 560X550X850 560X630X850 610X630X930 660X730X1340 910X900X1500 1670X1180X1500 Power supply voltage 220V 380V Phase number Single-phase Three Phase Heating element 1700 type silicon molybdenum rod Temperature control mode 一.Yudian temperature control 30 sections can only use PID temperature regulation. 二.FP93 temperature control (from Japan) (Replace imported instruments, for an additional fee) 1,40 section program temperature control can be divided into 4,2,1 group program,  if the program is divided into four groups, each program segment 10, 2,6 group PID control, low, medium and high temperature can each with a set of PID,  such that each segment is capable of controlling the temperature is very accurate. Control accuracy +/- 1 ℃ Heating rate ≤30 ℃/ Min Recommended heating rate 15℃/ Min Max temperature 1600 ℃ Rated temperature 1550 ℃ Surrounding surface temperature ≤35℃ Thermocouple Type Type B Triggers 1.Phase trigger (with soft start and current limiting function) 2.Current limiting function: no matter how to adjust the heating time,  our furnace transformer secondary current through the post is limited to 160A,  limited protection of equipment, no matter how you operate, the device will not burn. 3.Soft-start function: When the power current will slowly increase,  the impact on the heating element is small, help extend the life of the heating element SCR 106 / 16E Germany Semikron Certification CE  Email : tob.amy@tobmachine.com  Skype : amywangbest86  Whatsapp/Phone number : +86 181 2071 5609

SWCNT Single-walled carbon nanotubes SPECIFICATIONS Packing: 1g/bottle  Single-walled carbon nano tube (single layer carbon nano tube)  Purity  ≥99.7%  Diameter  0.75~3nm  Length  1~50um  Tensile Strength  800Gpa  Characteristic  Conductive, thermal conductivity, enhance toughness      Multi-walled carbon nano tubes  (multi layer carbon nano tubes)   Purity   ≥99.7%   Diameter   2~30nm   Length   0.1~50um   Tensile Strength   50~200Gpa   Number of layers   2~50   Interlayer spacing   0.34±0.01nm   Characteristic   Conductive, thermal conductivity, enhance toughness Carbon Tube Applied Range  Email : tob.amy@tobmachine.com  Skype : amywangbest86  Whatsapp/Phone number : +86 181 2071 5609
