18650 Battery Spot Welding Machine

This pneumatic spot welding machine is mainly used for 18650 cylinder cell pack welding, it can weld Nickel tab thickness from 0.02-0.2mm with good welding effect. For single point, used for Ni tab weld with steel case.

  • Brand:

    TOB NEW ENERGY

  • item no.:

    TOB-APR30

  • order(moq):

    1 set

  • Payment:

    L/C,T/T,Western Union

  • product origin:

    China

  • shipping port:

    XIAMEN

  • Lead Time:

    7 days
inquiry now
Product Detail

Table Single Point Pneumatic Welding Machine for 18650 Cylinder Cell Welder



SPECIFICATIONS


Microcomputer precision double pulse spot welding machine

This pneumatic spot welding machine is mainly used for 18650 cylinder call pack welding, it can weld Nickel tab thickness from 0.02-0.2 mm with good welding effect.

The Pneumatic model is with smaller volume and weight, easy for international shipping.

Sinlge point needle can be used for Ni tab weld with Stainless steel case.


1 Microcomputer control, CNC current adjust

2 High precision welding power

3 Digital tube display, keyboard control, welding parameters flash storage.

4 Double pulse welding, make welding more firmly.

5 Small welding sparks, solder joint uniform appearance, the surface is clean

6 Welding times can be set

7 Can set preloading time, the holding time, time to rest,  the welding speed can be adjusted.

8 Large power, stable and reliable.

9 Double needle pressure adjustable separately, Suitable for different thickness of Nickel strip.


Model

TOB-APR30

Controlmode

Pneumatic

Welding current

3000A

Welding power

0-99% adjustable

Welding method

Double pulse

Maximum output power

15KVA

Voltage supply

AC 220V±10% 50Hz±2Hz

Welding way

Ordinary welding and continuous automatic welding

Time setting

0-2.55s

Automatic counting function

yes

Weight

30kg

Dimensions

550*250*360mm

Package weight

40kg

Package size

630*330*430mm


PRODUCT DISPLAY


18650 table spot welding machine

Table spot welding machine

18650 battery welding

Long Welding Needle For Bottom Welding

  Cylinder battery welding machine welding needle


PACKAGE


18650 table spot welder


 Skype : amywangbest86

 Whatsapp/Phone number : +86 181 2071 5609
